BEA CONDOR - Mounting; Wiring

3/8
1
4
2
5
3
6
38 mm
76
152
158
65
165
158
WALL MOUNTING
CEILING MOUNTING
Minimum distances in mm required to fully adjust the sensor:
WIRING
MOUNTING
GREEN
BROWN
WHITE
YELLOW
GREY
PINK
VIOLET
BLACK
24V
GND
COM
NO*
NC*
COM
NC*
NO*
POWER
SUPPLY
RADAR
OUTPUT
MOTION SIGNAL
PRESENCE SIGNAL
IR
OUTPUT
YELLOW
VIOLET
NO POWER
NO POWER
NO DETECTION
NO DETECTION
DETECTION
DETECTION
GREY
BLACK
ACTIVEPASSIVE
STEP 2
STEP 1
*Powered, no detection
