BEA CONDOR - Product Description and Symbols; LED Signal and Symbols; Installation Tips

2/8
CONDOR
-5°C
+25°C
°C
p.2
Fasten the sensor
firmly in order to
avoid vibrations.
Do not cover the
sensor.
Avoid moving
objects in front of the
sensor
Avoid high intensity
lightning in the
detection field.
Push buttons
Fixing bracket
Radar detection sensor
Infrared detection sensor
Radar tilt angle
adjustment screw
LED
GREEN LED
RED LED
RED-GREEN LED
SEE PAGE 2
IMPORTANT!
PRESENCEMOTION
RADAR
IR
SETUP
LED
flashes quickly
LED
flashes slowly
LED
OFF
FACTORY
VALUE
INSTALLATION TIPS
LED-SIGNAL AND SYMBOLS
DESCRIPTION
MOTION & PRESENCE SENSOR FOR AUTOMATIC INDUSTRIAL DOORS
USER’S GUIDE
Avoid exposing the
sensor to sudden and
extreme temperature
changes.
