Page 2 of 4 75.1221.01 IXIO-ST QG 20230913
LED SIGNALS
CLOSERCLOSER
AWAYAWAY
Activate the visible spots. Adjust the angle, if necessary.
ANGLE
WIDTH
SETUP 1 (QUICK)
reference picture
SETUP 2 (ASSISTED)
test of full door cycle + reference picture
either hold the knob for 2 seconds, or use the
remote control buttons as specified
either hold the knob for 4 seconds, or use the
remote control buttons as specified
OR
OR
Always verify the actual detection field width by walk-testing according to ANSI 156.10.
DOOR
max.
3 in
STEP OUT OF THE INFRARED FIELD!
TEST THE PROPER OPERATION OF THE INSTALLATION BEFORE LEAVING THE PREMISES!
INFRARED SAFETY FIELD
SETUP
COLORS BEHAVIORS
(green)
AUX
(red)
Presence detection
LED flashes
LED flashes quickly
LED is off
LED flashes x times
LED flashes red-green
C1
C2
DIAGNOSTICS BASICADVANCEDDIAGNOSTICS
