Emergency Reserve Manifold
2005715.05
2.1.8 The pipework should be secured to the
wall using munsen rings (not supplied). It would
be recommended to t the rst pipe support to
the supplied ø22mm OD stub pipe (Item 12, gure
1). The next support should typically be tted
within 2m of the rst.
2.1.9 The ø28mm exhaust line (Item 13, gure
1) shall be brazed using uxless brazing technique
with nitrogen purge.
 CAUTION:Theø28mmexhaustline(Item
13,gure1)needstobepipedawayfromthe
manifold room to a safe location to prevent
buildup of waste gas in an enclosed space in the
event of a regulator failure.
CAUTION: Do not reduce the diameter of
thepipeusedfortheexhaustline.
Note - ‘J’ type cylinders typically for Oxygen and Medi-
cal Air.‘G’ type cylinders typically for Nitrous Oxide
and N2O/O2 mix (Entonox).
 CAUTION:Suppliedxingsareforuse
with solid masonry type walls only. Typical ERM
weight is 16kg.
Note - ‘VF’ size cylinders typically used for CO2
Figure 4 - Typical Installation For use with ‘VF’
Type Cylinders
 CAUTION:Suppliedxingsareforuse
with solid masonry type walls only. Typical ERM
weight is 16kg.
