BEAMEX MC5 - Recommended Calibration Points; E Module; ET Module; Pressure Modules

Calibration and Adjustment Instructions for MC5 Multifunction Calibrator For Main Firmware Version 1.90
Page 4/16
Recommended Calibration Points
The calibration points presented here are mostly the same as on the Calibration Certificate de-
livered with the calibrator. As the heading indicates, these are recommendations, not the only
suitable calibration points.
E module
Low Voltage
meas., V
(±1 V)
Voltage
meas., V
(±50 V)
Current
meas., mA
(±100 mA)
Current
generation, mA
(0 … 25 mA)
Frequency meas-
urement, Hz
(0.0027…50000 Hz)
-1.00000 -50.000 -100.000 0.000 1
0.00000 0.000 0.000 5.000 10
0.25000 10.000 4.000 10.000 100
0.50000 20.000 12.000 15.000 1000
0.75000 30.000 20.000 20.000 10000
1.00000 40.000 50.000 25.000 50000
50.000 100.000
ET module
Low Voltage
meas. & gen., mV
(±500 mV)
Voltage
gen., V
(±12 V)
Current gen.,
mA
(±25 mA)
Frequency genera-
tion, Hz
(2.7 mHz…50 kHz)
Resistance
meas., ohm
(0 … 4000 ohm)
Resistance
simul., ohm
(0 … 4000 ohm)
-500.00 -12.000 0.000 1 5.000 5.000
0.00 0.000 5.000 10 80.000 130.00
10.00 2.500 10.000 100 160.00 145.00
50.00 5.000 15.000 1000 320.00 270.00
250.00 7.500 20.000 10000 1000.00 290.00
500.00 10.000 25.000 50000 2000.00 540.00
12.000 4000.00 570.00
1050.00
1200.00
2100.00
2300.00
4000.00
Pressure modules
Barometric
module, kPa abs
(80…120 kPa)
Gauge
modules,
(0 … X kPa)
Combined modules with a
symmetrical range
(±X kPa)
Combined modules with
an asymmetrical range
(-100 … X kPa)
80.00 0 % of span 0 % of span 0 % of span
90.00 20 % of span 20 % of span 20 % of span
100.00 40 % of span 40 % of span 40 % of span
110.00 60 % of span 60 % of span 60 % of span
120.00 80 % of span 80 % of span 80 % of span
100 % of span 100 % of span 100 % of span
80 % of span 80 % of span 80 % of span
60 % of span 60 % of span 60 % of span
40 % of span 40 % of span 40 % of span
20 % of span 20 % of span 20 % of span
0 % of span 0 % of span 0 % of span
-20 % of span -20 kPa
- 40 % of span -40 kPa
- 60 % of span -60 kPa
- 80 % of span -80 kPa
- 100 % of span -99 kPa
Note. The exact values of the calibration
points may vary depending on the dead weight tester in use.
