Commissioning
EL500x 125Version: 3.6
Index 4068 SSI frame type (only EL5001)
Index (hex) Name Meaning Data type Flags Default
4068:0 SSI-frame type 0: Multi-turn analysis is active (25-bit data frame)
1: Single-turn-analysis is active (13-bit data frame)
2: Variable analysis is active. The length of the data
frame (1 to 32 bit) is specified via object 0x4069
[}125].
UINT16 RW 0x0000 (0
dec
)
Index 4069 SSI frame size (only EL5001)
Index (hex) Name Meaning Data type Flags Default
4069:0 SSI frame size Length of the SSI data frame (in bits)
Min. : 0
dec
Max.: 32
dec
UINT16 RW 0x0019 (25
dec
)
Index 406A data length (only EL5001)
Index (hex) Name Meaning Data type Flags Default
406A:0 Data length Data length
Min. : 0
dec
Max.: 32
dec
UINT16 RW 0x0018 (24
dec
)
Index 406B min. inhibit time [µs] (only EL5001)
Index (hex) Name Meaning Data type Flags Default
406B:0 Min. inhibit time[µs] Minimum inhibit time in µs (1 to 65535) UINT16 RW 0x0000 (0
dec
)
