Commissioning
EL500x126 Version: 3.6
Index 80n0 SSI settings (only EL5002), with n=0 (Ch.1), n=1 (Ch.2)
Index (hex) Name Meaning Data type Flags Default
80n0:0 SSI settings Length of this object UINT8 RO 0x13 (19
dec
)
80n0:01 Disable frame error 0: Frame error is not suppressed
1: Frame error is suppressed
BOOLEAN RW 0x00 (0
dec
)
80n0:02 Enable power failure
bit
0: Power failure bit is not active
1: Power failure bit is active: The last bit of the data
frame (encoder-specific error bit) is shown as error
bit in 0x60n0:03 [}128] of the status word.
BOOLEAN RW 0x00 (0
dec
)
80n0:03 Enable inhibit time 0: Inhibit time is not active
1: Inhibit time is active
BOOLEAN RW 0x00 (0
dec
)
80n0:04 Enable test mode 0: Test mode is not active
1: Test mode is active
BOOLEAN RW 0x00 (0
dec
)
80n0:06 SSI coding 0: Binary code active
1: Gray code active
BIT1 RW 0x01 (1
dec
)
80n0:09 SSI baud rate 0: reserved
1: 1250 kbaud
2: 1000 kbaud
3: 500 kbaud
4: 250 kbaud
5: 125 kbaud
6 - 65535: reserved
BIT3 RW 0x03 (3
dec
)
80n0:0C***
Enable SSI clock jitter
compensation
[}115]***
0: SSI dock jitter compensation is disabled (default)
1: SSI dock jitter compensation is enabled
BIT3 RW 0x00 (0
dec
)
80n0:0F SSI-frame type 0: Multi-turn analysis is active (25-bit data frame)
1: Single-turn-analysis is active (13-bit data frame)
2: Variable analysis is active. The length of the data
frame (1 to 32 bit) is specified via object 0x80n0:11
[}126].
BIT2 RW 0x00 (0
dec
)
80n0:11 SSI frame size Length of the SSI data frame (in bits)
Min. : 0
dec
Max.: 32
dec
UINT16 RW 0x0019 (25
dec
)
80n0:12 SSI data length Data length
Min. : 0
dec
Max.: 32
dec
UINT16 RW 0x0018 (24
dec
)
80n0:13 Min. inhibit time[µs] Minimum inhibit time in µs (1 to 65535) UINT16 RW 0x0000 (0
dec
)
80n0:14***
Number of clock
bursts [}115]***
Number of clock bursts
1: single transmission is active (Default)
2: multiple transmission with 2 clock bursts
3: multiple transmission with 3 clock bursts
UINT16 RW 0x0000 (0
dec
)
***) from FW03
