Product overview
EL9xxx 33Version: 3.9
Technical data
Technical Data EL9181 EL9182 EL9183
Technology Potential distribution terminal
Number of separate potentials 2 8 1
Terminal points per potential 8 2 16
Nominal voltage ≤ 60 V
DC
Current load max. 10 A
Current consumption from E-Bus -
E-bus looped through yes
Power contacts looped through yes (2 power contacts)
Diagnosis -
Message to E-Bus -
PE contact no
Renewed infeed -
Connection facility to additional power con-
tact
-
Side by side mounting on Bus Terminals
with power contact
yes
Side by side mounting on Bus Terminals
without power contact
-
Bit width in the process image 0
Electrical connection to mounting rail -
Electrical connection to power contacts -
Electrical isolation 500 V (E-bus/field potential)
Configuration no address or configuration settings
Conductor types solid wire, stranded wire and ferrule
Conductor connection solid wire conductors: direct plug-in technique; stranded wire conductors and ferrules:
spring actuation by screwdriver
Rated cross-section solid wire: 0.08…1.5 mm²; stranded wire: 0.25…1.5 mm²; ferrule: 0.14…0.75 mm²
Weight approx.. 60 g
Permissible ambient temperature range
(during operation)
-25°C ... +60°C (extended temperature range)
Permissible ambient temperature range
(during storage)
-40°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Mounting [}73]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance
conforms to EN60068-2-6/EN60068-2-27, see Installation instructions [}76] for en-
hanced mechanical load capacity
EMC resistance burst/ESD conforms to EN 61000-6-2/EN 61000-6-4
Protect. class IP 20
Installation pos.
variable, see chapter "Mounting of Passive Terminals [}83]"
Approval CE
cULus [}86]
Connection EL9181
Terminal point Meaning
Indication No.
1 - 8 1 - 8 Terminal points 1 - 8 are connected internally
9 - 16 9 - 16 Terminal points 9 -16 are connected internally
