Product overview
EL9xxx34 Version: 3.9
Connection EL9182
Terminal point Meaning
Indication No.
1, 9 1 + 9 Terminal points 1 + 9 are connected internally
2, 10 2 + 10 Terminal points 2 +10 are connected internally
3, 11 3 + 11 Terminal points 3 + 11 are connected internally
4, 12 4 + 12 Terminal points 4 + 12 are connected internally
5, 13 5 + 13 Terminal points 5 + 13 are connected internally
6, 14 6 + 14 Terminal points 6 + 14 are connected internally
7, 15 7 + 15 Terminal points 7 + 15 are connected internally
8, 16 8 + 16 Terminal points 8 + 16 are connected internally
Connection EL9183
Terminal point Meaning
Indication No.
1 - 16 1 - 16 Terminal points 1 -16 are connected internally
