Product overview
KL6031/KS6031, KL6041/KS6041 9Version: 2.1.0
Connections
Terminal point Name Signal
1 TxD Signal line (Transmit Data)
5 RxD Signal line (Receive Data)
2 RTS Control line (Request To Send)
6 CTS Control line (Clear To Send)
3 GND Ground (internally bridged with terminal 7)
7 GND Ground (internally bridged with terminal 3)
4 Shield Shield (internally bridged with terminal 8)
8 Shield Shield (internally bridged with terminal 4)
2.2 KL6031 - Technical data
Technical data KL6031, KS6031
Data transfer channels 2 (1/1), TxD and RxD, full duplex
Data transfer rate 9600bit/s, 8 data bits, no parity and one stop bit are
pre-set (max. 115200bit/s)
Bit distortion < 3%
RS232 cable length max. 15m
Signal voltage "low" -18V ... -3V
Signal voltage "high" 3V ... 18V
Power supply via the K-bus
Electrical isolation 500V (K-bus/signal voltage)
Data buffer 1024 byte receive buffer, 128 byte transmit buffer
Bit width in process image input/output: 22 x 8 bit user data, 2 x 8 bit control/
status (up to 22 bytes of user data possible)
Configuration no address setting, configuration via bus coupler or
controller
Current consumption from K-bus 55mA
Weight approx.50g
Permissible ambient temperature range during
operation
-25°C ... +60°C (extended temperature range)
Permissible ambient temperature range during
storage
-45 °C ... +85 °C
Permissible relative humidity 95% no condensation
Mounting [}15]
on 35mm mounting rail according to EN60715
Pluggable wiring for all KSxxxx terminals
Enhanced mechanical load capacity
yes, see Installation instructions [}17] for enhanced
mechanical load capacity
Vibration/ shock resistance conforms to EN60068-2-6/ EN60068-2-27
EMC immunity/ emission conforms to EN61000-6-2/ EN61000-6-4
Protection class IP20
Installation position variable
Approvals/markings*
CE, UKCA, cULus, EAC, GL, ATEX [}22]
*) Real applicable approvals/markings see type plate on the side (product marking).
Ex marking
Standard Marking
ATEX II 3 G Ex nA IIC T4 Gc
