Beckhoff XPlanar User Manual

Mechanical Installation – Part 2: Mover
70 ─── Version: 1.0XPlanar
9.1.5Mover coupling
Two, four or six movers can be coupled with a frame. Regardless of
the mover design, the following requirements must be met for the
coupling:
• 240mm center distance between movers
• Rectangular arrangement of the movers
• Use the same mover version, e.g. only APM4550-0000
The center distance ensures an almost linear increase in payload.
The total payload can be calculated by multiplying the number of
movers by the maximum payload of a mover minus the frame
weight:
A x B C = D ‒
Variable Explanation
A Number of movers
B Maximum load of a mover
C Frame weight
D Total payload
For further information on mover coupling, please contact your local
Beckhoff office or support@beckhoff.com.
9.1.5.1Preparation
Before you start coupling movers, you must provide a suitable
frame, assembly aids and screws. Frames, assembly aids and
screws are not part of the scope of supply.
9.1.5.1.1Frame
Dimensional drawings and 3D models online
The dimensional drawings and 3D models for the frame are avail-
able for download from the Beckhoff website:
www.beckhoff.de/download
Beckhoff recommends the following material for the frame:
• Aluminum
9.1.5.1.2Assembly aids
Dimensional drawings and 3D models online
The dimensional drawings and 3D models for the assembly aids
are available for download from the Beckhoff website:
www.beckhoff.de/download
The assembly aid must be made of non-magnetic material. Beckhoff
recommends the following material:
• Wood, plastic or aluminum
The assembly aid weakens the magnetic field of the movers, but the
permanent magnetic field on the underside of the movers is still
present.
