BEIER-Electronic USM-RC-3 - Wiring Diagram Digital Mode with UFR Speed Controller

GB Sound module USM-RC-3
12 BEIER-Electronic 11.10.2021
RC receiver
Servo
Servo
1
Servo
2
Servo
3
Volume
100k
Battery
5 - 15 V
(max.
4S LiPo)
+
-
Outputs minus
switching
Servo
4
Servo
Servo
Throttle
Prop #2 Prop #3 Prop #4 Prop #5 Prop #6 (BTC-1) Prop #7 Prop #8 (S-BUS, SUMD, i-BUS)
Servo
- +
Loudspeaker
4 - 8 Ohm
Kraftwerk
EasyBus
IR / BT
transmitter
Data cable
K-USB-2
e.g. switching module
Input 1
Input 2
Input 3
Input 4
Output 17
(high current,
max. 3 A)
4 A
Fuse
(important!)
Main
switch
USM-RC-3
Micro
SD card
1 - 32 GB
(optional)
+ -
X1
X4/1
UFR-
1230(-D)
Output 9 Output 10 Output 11 Output 12 Output 13 Output 14 Output 15 Output 16
Output 1 Output 2 Output 3 Output 4 Output 5 Output 6 Output 7 Output 8
braun red orange yellow green blue purple grey white / black
brown red orange yellow green blue purple grey white / black
Wiring diagram Digital mode with UFR speed controller
