BEIER-Electronic USM-RC-3 - Technical Data

GB Sound module USM-RC-3
6 BEIER-Electronic 11.10.2021
Technical data
Supply Voltage (U
b
):
5 – 15 V DC
Power consumption:
Standby current: approx. 80 mA
Operation: The current consumption depends
on the volume and the switched load.
Proportional inputs:
8 inputs
Supported protocols:
• PPM / PCM (1,000 - 2,000 ms)
• Sum signal S-Bus (max. 16 channels)
• Sum signal i-Bus (max. 16 channels)
• Sum signal SUMD / SUMD3 (max. 16
channels)
• Nautic / Multiswitch / Multikanal / EMS
Inputs:
4 inputs
LO signal = U < 2 V
HI signal = U > 5 V
Integrated pull-up resistors (approx. 15 kΩ)
Servo outputs:
4 outputs (1,000 - 2,000 ms)
Switching outputs:
• 16 outputs (negative switching, open
collector), max. 1,5 A each output, the total
current of all outputs is not allowed to
exceed 3,0A
• 1 high current output (negative switching,
open collector) max. 3,0 A
Audio amplifier:
20 W (mono)
Recommended loudspeaker:
4 – 8 Ω
Volume setting:
With extra poti (100 kΩ) and/or by the radio
Memory for sound files:
Micro SD card (1 to 32 GB)
May. length of sound:
approx. 180 minutes per 1 GB
Supported file format:
WAV-Format, 8/16 Bit, Mono/Stereo, 22/44 kHz
Sound output:
16 Bit, Mono, 44 kHz
Number of possible sounds:
• 5 running steps/gears (internally in up to 255
steps accelerated)
• 8 change sounds between the running
steps/gears
• Turn on noise, turn off noise, starting noise,
stopping noise, idling noise, brake noise,
reverse warning, curve squeal, flashing lights
sound
• 30 additional sounds (for example via prop.-
channels)
• 8 random sounds (random generator)
•
30 tracks for WAV-Player
Random sound generator:
Times between 1 to 999 s adjustable
