GB Sound module USM-RC-3
54 BEIER-Electronic 11.10.2021
Outputs for military vehicles: „black out headlamp“, „disguise rear light“,
„disguise brake light“ und „guidance cross“
These outputs can only be switches with the programmable light switch (see page
83) using the functions "light switch +" and "light switch -".
Transmission of the outputs to a trailer light module
The outputs 1 - 12 of the USM-RC-3 can be transmitted to our IR light module SM-
IR-16-2 via an infrared signal.
The outputs 1 - 16 of the USM-RC-3 can be transmitted via infrared signal to our light
module LM-IR-16-4 or via Bluetooth to the light module LM-BT-16-4.
Other light modules are not compatible.
Attention:
The outputs 13 - 16 of the USM-RC-3 can unfortunately not be transferred to the
SM-IR-16-2! The outputs 13-16 of the SM-IR-16-2 can only be used for special
functions such as flashing or running lights (see manual for the SM-IR-16-2).
Output sequences
You can assign the outputs 1 - 16 in up to 8 sequence groups.
In the Sound-Teacher up to 36 steps can be programmed for each of the eight
sequences (see page 84). For every step, you can program which output is switched
on and the intensity of the outputs.
Moreover, the duration of every step until it goes on to the next one can be
configured.
Is an output sequence enabled, the sequence always takes precedence over the
normal function (eg, indicators, parking lights, etc.) of the output. The normal function
of the output is switched off during the active sequence.
With these output sequences, the most amazing light effects can be generated.
Examples:
• Rotating lights
• Moving lights
• Modern police flashlights
• Beacon lights for airplanes
• Switching on flickering of fluorescent lamps
• Any flickering lights and flash lights
