GB Sound module USM-RC-3
11.10.2021 BEIER-Electronic 37
• Servo 1 - 4 position 1 - 4
• Servo 1 - 2 sequence
modules SM-IR16-2,
LM-IR-16-4 and
LM-BT-16-4
• Servo 1 - 2 position 1 - 2
• Servo 3 - 4 position 1 - 2 (only LM-xx-16-4)
• Motor up / down (only LM-xx-16-4)
• Rotating beacon
• Blinker lights/flash lights
• Chaser light
• Transmission off
• Activate road train ID 1 - 7 (only LM-xx-16-4)
All functions can be triggered by the proportional channels, the Nautic-mode, the
EKMFA-mode and the switching inputs. The assignment in the Sound-Teacher is
very flexible.
Additional sounds 1 - 30
In addition to the engine sound, the USM-RC-3 can play up to 30 additional sounds.
Typical sounds are e.g. horns, hydraulic and pneumatic noises, warning horns,
shooting noises, Songs, radio calls, and so on. There are nearly no limits set to your
imaginations.
To play an additional sound, it must be started over a start impuls. This can be done
by using the proportional channels, the Nautic-mode, the EKMFA-mode or the
switching inputs.
Additional sounds 1 and 2 offer a special feature:
Each of these sounds consists of 3 single sound slots. When the additional sound 1
is started, the slot “start” is played first. Then the sound changes to the slot “loop”
and plays this slot in an endless loop so long as the start signal for the additional
sound 1 is still present. When the start signal for additional sound 1 disappears, the
slot “stop” is played uniquely. Additional sound 2 works in the same way.
In this way, a sound like a ship horn with variable length (without a hard cut at the
end), can be realized. Also for example a MG fire can be fitted with a great
reverberation.
The start and stop slots are only options that can be used. You can let these slots
also free.
For additional sounds 3-30 various play-back modes can be set up using the USM-
RC Sound-Teacher. Thereby it is possible to fine-tune every additional sound to
produce a perfect match to your particular mode.
