GB Sound module USM-RC-3
42 BEIER-Electronic 11.10.2021
Difference between static and memory function:
If a function is defined as static, it will be
switched on as long as the joy-stick is in
the corresponding area. If you leave the
area, the function will be switched off
again.
If a function is defined as memory and
you move the joy-stick for the specified
time (short or long) in the corresponding
area, it will be switched on. If you leave
the area, the function remains switched
on (it is saved). It remains on, until the
the joy-stick is moved in the
corresponding area again. Exceptional
are additional sounds with the setting
"once" in "Additional sound". Despite a
memory setting in "Configuration" the
sound is played only once.
You can read on page 36, which functions can be assigned to the 4 areas A, B, C
and D.
The proportional channels # 2, # 3, # 4, # 6 and # 8 have different special functions:
Proportional channel # 2
The steering channel can be evaluated on proportional channel #2. The turn signals
or cornering lights can be activated automatically when steering.
Proportional channel #3
Channel #3 is used to trigger functions via EKMFA mode, Nautic 1 or control pad 1.
Proportional channel l #4
Nautic/multiswitch module Nautic 2 or control pad 2 can be activated at channel #4.
Proportional channel #6
The Bluetooth controller BTC-1 is connected to Prop # 6. The sound module can
also be controlled via an Android app.
Proportional channel #8
Sum signals, such as S-BUS, SUMD and i-BUS are received via to channel #8.
Alternatively, a "normal" assignment (function triggering via the areas A, B, C and D)
of the channels #2 - #8 are of course also possible.
Neutral position of channels
The neutral positions of the proportional channels #1 and #2 are read in again each
time the USM-RC-3 is started. It must therefore be ensured that when the USM-RC-3
is switched on, the throttle and steering on the radio are in neutral.
The neutral positions of all other channels are fixed at 1.500 ms.
