7 Specification
BFI-E3 (1 x 230 V) BFI-E3 (3 x 400 V)
Drive Model
023 043 070 105 153 022 041 058 095 140 180 240 300 390 460 610 720
Output power, kW 0,37 0,75 1,5 2,2 4,0 0,75 1,5 2,2 4,0 5,5 7,5 11 15 18 22 30 37
Output current A, 2,3 4,3 7,0 10,5 15,3 2,2 4,1 5,8 9,5 14 18 24 30 39 46 61 72
Overload rating, A 175 % av märkström i 2,0 sek; 150 % i 1 min
Output voltage 3-fas, 0 V upp till ansluten nätspänning
Output frequency 0 – 500 Hz
Input voltage 1-fas, 200 – 240 VAC 3-fas, 380-480 VAC
Voltage fluctuations 180 – 264 VAC 342 – 528 VAC
Input frequency 48-62 Hz
Input current A 3,7 7,5 13 19 29 3,5 5,6 7,5 12 17 21 27 34 44 52
Internal Braketransitor No Option Yes No Optio Yes
Control methods Linear U/f-reglering, Adjustable linear, Vector control, Energy Optimised
Motors Induction motors, PM-motor, BLDC, Synchronus reluctance motor
Start methods Digital, Push button Fwd/Rev/Stop, Keypad, Modbus RTU, CANopen
Frequency setpoint Digital Preset speed, Digital motorpotentiometer, Analog 4–20 mA, 0–5 V, Keypad, Modbus RTU, CANopen
Digital input
2 x Programmable Digital Input and 2 x User-selectable Digital or Analog Inputs,
Analog input
2 x User-selectable Digital or Analog Inputs. 4-20 mA or 0-10 V or -10 to 10. 12 bit
Transistor output
1 x User-selectable Digital or Analog Output. Maximum current 20 mA.
Relay output
1 x Progammable Relay (single pole), Maximum load 6,0 A with 230 V or 5A with 30 VDC.
Analog output
1 x User-selectable Digital or Analog Output, 0-10 V DC. Maximum current 20 mA. 10 bit.
Communication
Modbus RTU or CANopen
Acc/Deceration time 0 to 600 sec, 2:nd deceleration ramp
Stop mode Ramping / Fast stop / Coasting / DC-brake
Motor overload
protection
Internal control of output current in combination with motor current setting. Digital or analog overload signal
connectable as standard. Trip level for is a resistance above 2,5 kOhm.
Functions
PI-control with Sleep mode, Spin start, Automatic restart, Skip frequency, Stop method at Voltage
interruption, Enery Optimiser, Parameter access lock, Firemode
Protection class IP20 or IP66
Ambient temperature IP20: -20 ºC to +50 ºC, IP66: -20 ºC to +40 ºC, Storage temperature -40 ºC to +60 ºC
Maximum humidity Max. 95 % non-condensing
Environment
No airborne dust, corrosive gases or liquids, conductive contaminants (such as condensation, carbon dust,
and metallic particles), high moisture, salt or chemical content environments.
3C3/3S3 conformal coated PCBs.
Maximum altitude 2000 meter bove sea level, Derate avove 1000 m: 1 %/100m
Vibrations IEC 60068-2-29, IEC 60068-2-64, IEC 60068-2-6
Earth leakage current 1-fas 230 VAC: < 2,5 mA; 3-fas 400 VAC: < 4,65 mA
EMC 2014/30/EU, Built-in EMC-filter, All models fullfill EN61800-3:2004, Class C1, C2, C3 och C4
Machinery Directive 2006/42/EC
Low Voltage Directive
Adjustable speed electrical power drive systems
Approvals CE, UL, RoHS, Carbon Trust
Max motorcable
length
100 m 100 m
Cooling fans IP66 Nej Internal fan Internal fan Not in IP66
Cooling fans IP20 Nej Fan in cooling fin Fan in cooling fin
Frame size 1 1 1 / 2 2 3 1 1 / 2 2 2 3 3 3 4 4 4 5 5
Weight IP20 [kg] 1,0 1,7 3,2 1,0 1,7 3,2 9,1 18,1
Weight IP66 [kg] 3,0 4,2 7,7 2,5 3,5 7,0 9,5 Not
