Beijer Electronics BFI-E3 Series User Manual

Beijer Electronics Frequency Inverter BFI-E3 KI00369B 2019-09
www.beijer.se www.beijer.no www.beijer.dk www.beijerelectronics.de www.beijerelectronics.com www.beijerelektronik.com.tr 3 (24)
4 Installation
The drive should be mounted in a vertical position only on a flat, flame resistant vibration
free mounting using the integral holes. IP66 is allowed for outdoor mounting. But it is
recommended having an external roof to avoid snow directly on drive. BFI will not start if
ambient temperature is below -20°C. See User Manual BFI-E3 for more details.
4.1 Physical dimensions IP20
BFI-E3- IP20
Drive
size
A
Height
[mm]
B
[mm]
C
[mm]
D
[mm]
E
[mm]
F
Depth
[mm]
G
Width
[mm]
H
[mm]
I
[mm]
J
[mm]
Weight
[kg]
1 x 230 V 3 x 380-480 V
0023-
0070
[0,37-1,5 kW]
0022-0041 [0,75-1,5kW]
1 173 160 109 162 5 123 83 50
5,5 10
1,0
0070-
0105
[1,5-2,2 kW]
0041-0095 [1,5-4,0 kW]
2 221 207 137 209 5.3 150 110 63 1,7
0153/ 4,0 kW
0140-0240 [5,5-11kW]
3 261 246 - 247 6 175 131 80 3,2
No
0300-0460 [15-22kW]
4 420 400 - 400 8 212 171 125 8,2 14,8 9,1
No
0610-0720 [30-37kW]
5 486 463 226 222 175 18,1
NOTE
1x230 BFI-E3-0070 and BFI-E3-0041 are without brake transistor for Size 1 and Size2 with.
Mounting bolts for Size1 to Size 3 are 4xM4 and 4xM8 for Size4 and Size5.
Control Terminal Torque Settings of 0.8Nm.
Power Terminal Torque Settings: Size1-3 = 1 Nm, Size4=2.0 Nm, Size5=4.0 Nm.
Drive IP-class
and
Size
X [mm]
Above &
Below
Y [mm]
Either
Side
Z [mm]
Between
drives
Minimum
Airflow
[m3/min]
IP20, size 1 50 50 33 0,14
IP20, size 2 75 50 46 0,27
IP20, size 3 100 50 52 0,74
IP20, size 4 100 50 52 1,48
IP20, size 5 200 25 70 1,28
IP66, All sizes 200 10 0 0
Z means that BFI can be mounted side-by-side. Minimum airflow is
based on maximum output power at 50°C for IP20 and 40°C for IP66.
