6.7 Monitoring from Keypad
Parameter group 0 contain variables to be monitored as table below:
Description
Display range
Explanation
P0-01
1st Analog Input Value
-100 % to 100%
100% = max input voltage
P0-02
2nd Analog Input Value
0 to 100%
100% = max input voltage
P0-03
Digital Input Status
00000 to 11111
MSB: Dig In1 / LSB: Dig In 5
P0-04
Speed Reference Input
-P1-01 … P1-01
Displayed in Hz if P-10 = 0, otherwise displayed in RPM
P0-07
Fieldbus Speed Reference
-P1-01 … P1-01
Displays se-point received from Fieldbus interface.
P0-08
PID Reference
0 to 100 %
Displays the setpoint input to the PID controller.
P0-09
PID feedback
0 to 100 %
Displays the feedback value to the PID controller.
P0-11
Motor Voltage
0 … 600V AC
Value of RMS voltage applied to motor
P0-13
Trip Log
Displays the four latest fault codes
P0-19
Cascade Run Time Log
hours
Run Time values for pumps in cascade mode.
0 = Master, 1 = Pump1, 2 = Pump2
P0-20
DC Bus Voltage
0 … 1000V dc
Internal DC bus voltage
P0-21
Internal Temperature
-20 … 100 °C
Temperature of heatsink in
°
C
P0-22
Time Left to next service
When 0 => service indicator is led on the display
P0-26
kWh meter
0 to 999,9
When overflow P00-27 increases by 1 and reset to 0.
P0-27
MWh meter
0 to 65535
Displays the amount of energy consumed by the drive.
P0-28
Software Version
I/O-version, I/O Checksum, DSP version, DSP checksum.
P0-29
Drive Type
Frame size, Power rating and output phases
P0-30
Drive Serial Number
Unique drive serial number.
P0-31
Total Run Time
0 to 99999 hours
Displays the total operating time of the drive.
P0-35
Fan Run Time
0 to 99999 hours
Displays total operating time of internal cooling fans.
P0-36
DC Bus Voltage at Trip
V DC
Values logged before trip with 8 samples total (256 msec).
P0-37
DC Bus Voltage Ripple at Trip
V DC
Values logged before trip with 8 samples total (20 msec).
P0-38
Heatsink Temperature at Trip
-20 … 100 °C
Values logged before trip with 8 samples total (30 sec).
P0-39
Ambient Temperature at Trip
°C
Values logged before trip with 8 samples total (30 sec).
P0-40
Motor Current Log at Trip
A
Values logged before trip with 8 samples total (256 msec).
P0-41
Over Current Fault Counter
Over Current fault counter
P0-42
Over Voltage Fault Counter
Over Voltage fault counter
P0-43
Under Voltage Fault Counter
Under Voltage fault counter
P0-44
Heatsink Over Temperature
Heatsink Over Temperature fault counter
P0-45
Brake Chopper Short Circuit
Brake Chopper Short Circuit fault counter
P0-46
Ambient Over Temperature
Ambient Over Temperature fault counter
P0-49
Modbus RTU / BACnet
Modbus RTU/BACnet communication fault counter
P0-58
Load Torque Profile Current
Values
A
5 Autotuned values of Load Torque Characteristic function.
First display –Current at minimum speed
Second display –Current at first measurement interval
Third display –Current at second measurement interval
Fourth display –Current at third measurement interval
Fifth display –Current at maximum speed
P0-64
Switching Frequency
kHz
Displays the actual effective Switching frequency
P0-65
Drive Life Time
Powered up time, hours, min, and sec
P0-70
Option Module ID-code
Identifies Type of Option Module in option module slot
P0-71
Fieldbus module ID
Fieldbus module Identification Code
