4 Installation
The drive should be mounted in a vertical position only on a flat, flame resistant, vibration free
mounting using the integral holes. IP55/66 is allowed to be mounted outdoors but must be
protected from sunlight and it also recommended having a roof to avoid snow directly on the
drive. BFI will not start if ambient temperature is below 10 Celsius. See User Manual BFI-H3
for more details.
4.1 Physical dimensions IP66, Outdoor rated
BFI-H3-IP66
Drive
size
A
Height
[mm]
B
Width
[mm]
C
Depth
[mm]
D
[mm]
E
[mm]
F
[mm]
Weight
[kg]
1 x 230 V
3 x 230 V
3 x 400 V
0043 – 0105
[0,75–2,2 kW]
0043 – 0105
[0,75–2,2 kW]
0022 – 0140
[0,75- 5,5 kW]
2
257
188
186
200
176
172
4,8
None
0180 – 0240
[4,0 – 5,5 kW]
0180 – 0300
[7,5 – 15 kW]
3
310
211
235
252
198
225
7,7
None
0300 – 0460
[7,5 – 11 kW]
0390 – 0460
[18 – 22 kW]
4
360
240
271
227
230
260
9,5
NOTE
Mounting Bolts
All Sizes: : 4 x M4.
Required tightening Torque Control terminals
All Sizes: : 0,5 Nm.
Required tightening Torque Power terminals
Size 2 and 3: 0,8 Nm; Size 4: 2 Nm
Drive IP-
class and
Size
X [mm]
Above
&
Below
Y
[mm]
Either
Side
Z [mm]
Between
drives
Minimum
Airflow
[m3/min]
IP20, size 2
75
10
46
0,3
IP20, size 3
100
10
52
0,9
IP20, size 4
200
25
70
1,7
IP20, size 5/6
200
25
70
2,9
IP20, size 8
350
50
412
20
All IP55 and
IP66
200
10
10
No require-
ment
Note
All BFI-H3 IP20 can be mounted close to each
without any space in between
