G+ MIMO Wireless Modem Router
SECTIONSTable of Contents 1 2 3 4 5 6 7 8 109
TROUBLESHOOTING
Problem:
I am having difficulty setting up Wired Equivalent Privacy (WEP) security on a Belkin client card (Wireless Network Card or Adapter)�
Important: A WEP key is a combination of numbers and letters from
A–F and 0–7� For 128-bit WEP, you need to enter 26 keys� This network
key needs to match the key you assign to your Wireless Router or
access point�
For example: C3030FAF4BB2C3D44BC3D4E7E4 = 128-bit key
7. Click “OK”, and then “Apply” to save the settings�
If you are NOT using a Belkin wireless client card, please consult the
manufacturer’s user manual for that wireless client card�
Solution:
The client card must use the same key as the Wireless Router or access point� For instance, if your Wireless Router or access point uses the key
00112233445566778899AABBCC, then the client card must be set to the exact same key�
1. Double-click the “Signal Indicator” icon to bring up the “Wireless
Network Utility” screen� The “Advanced” button will allow you to
view and configure more options of your client card�
2. Once the “Advanced” button is clicked, the Belkin Wireless LAN
Utility will appear� This Utility will allow you to manage all the
advanced features of the Belkin client card�
3. Under the “Wireless Network Properties” tab, select a network
name from the “Available Networks” list and click the “Properties”
button�
4. Under “Data Encryption”, select “WEP”�
5. Ensure the box “The key is provided for me automatically” at the
bottom is unchecked� If you are using this computer to connect to
a corporate network, please consult your network administrator if
this box needs to be checked�
6. Type your WEP key in the “Network key” box�
To Next Page
