Bell System CS106 - Cable Requirements

CS106/BL106 Combined Door Entry and Coded Access
10
Cable Requirements
Cable Types
0.5mm: Twisted pair, e.g. BT spec CW1308 or CAT5 UTP
1.0mm: 1.0mm
2
‘Twin mains flex’
Connections
No. of cores
Cable length
Core diameter
Power supply 2 up to 15M
up to 50M
0.5mm
1.0mm
Lock release (up to
500mA)
2 up to 5M
up to 25M
0.5mm
1.0mm
Time Clock 4 100M max. 0.5mm
Exit button 2 100M max. 0.5mm
In most cases cable length restrictions should not present a problem, however
where longer lengths are required please refer to the manufacturer for advice.
