CS106/BL106 Combined Door Entry and Coded Access
16
Programming the C106 Keypad
General
The 10 access codes, lock time etc, are all programmed via the keypad. To
prevent unauthorised use, a security key (1 - 8 digits) must be entered.
The basic principle of programming is as follows:
Each program function is described in detail on the following pages.
■ Enter the security key (1 to 8 digit number, default 1212). Check
the red LED flashes continuously.
■ Enter a key sequence on the keypad.
■ Observe both the red and green LEDs flash for one second.
■ When all functions are programmed, exit program mode by
pressing
