Benchmark DAC3 HGC - Page 60

Instruction Manual for DAC3 HGC and DAC3 L with 2.X Firmware Page 60
Graph 14 - THD+N versus Sample Rate
The THD+N performance of the DAC3 is identical at all Sample Rates.
Audio Precision
DAC3 - THD+N vs Sample Rate, 1 kHz at 0 dBFS (w/20 kHz LPF unweighted)
DAC3 - THD+N vs Sample Rate.at27
ColorSweep Trace Line Style Thick
Data Axis Comment Cursor1 Cursor2
1
1 Green Solid
4 Anlr.THD+N Ratio Left Left Channel
-113.043 dB -113.041 dB
1 2
Red Solid 4 Anlr.THD+N Ratio Left Right Channel *-113.209 dB *-113.208 dB
-130
-90
-125
-120
-115
-110
-105
-100
-95
-113.209
-113.208
d
B
40k
200k 60k
80k
100k 120k
140k 160k 180k
28k
210k
Hz
dx=182.000 kHz
dy=+0.001 dB
