CC613 charge controller
2.7 LED indications
STATUS LED
Front plate
Orange Power on/system not ready for operation
Blue System is starting
Green System started, not yet ready for operation
Flashing green System running, system ready for operation
Red System error
Ethernet
Terminal D
O No Ethernet connection
Steady green Ethernet connection at 100 Mbit/s
Flashing green Data exchange at 100 Mbit/s
Steady yellow Ethernet connection at 10 Mbit/s
Flashing yellow Data exchange at 10 Mbit/s
CC613_D00381_07_M_XXEN/02.2023 11
