Function
2 Function
Local access to charge controller
Local access to the charge controller is possible either as the operator or as the manufacturer. Further
details are described in chapter 5.1.1. Operator access is possible via the http://192.168.123.123/
operator:
User name: operator
Password: yellow_zone
The Manufacturer can access the manufacturer area via the URL http://192.168.123.123/manufacturer:
User name: manufacturer
Password: orange_zone
The default passwords should be changed to prevent unauthorised access.
2.1 Intended use
The CC613 charge controller, hereinafter referred to as "charge controller", is the main component of a
charging system. It is intended for use in electric vehicle charging stations, wallboxes or street light charging
points. The charge controller controls type 1 and type 2 socket-outlets as well as attached cables. It enables a
setup that complies with the requirements of current standards, e.g. IEC 61851-1 and IEC 62955.
2.2 Device features (depending on the variant)
Charge controller in accordance with IEC 61851-1 (charging mode 3)
Congurable master and slave operation
Setting up charging stations with two charging points:
1 charge controller as data gateway with 4G modem
1 charge controller as slave without 4G modem
Dynamic load management to optimally distribute the available power among all charging points and
signal the maximum power available in each case to the vehicle
Residual direct current monitoring module (external RCD type A required), dierent cable lengths can be
selected
Integrated emergency opener for actuator control (locking/unlocking) and monitoring of the 12 V supply
voltage
Can be integrated in single- or three-phase systems up to 80 A
OCPP 1.5 and OCPP 1.6 compliant with JSON, SOAP
Supported mobile networks: 4G (LTE), 3G (UMTS) and 2G (GSM) with an integrated 4G modem
3 USB interfaces:
1 CONFIG interface for local conguration and installation of software updates
2 USB host interfaces
Control Pilot and Proximity Pilot communication
Congurable support for additional SCHUKO socket-outlets
Meter interface: Modbus TCP and RTU
External Modbus interface (second meter for dynamic load management)
User interface modules for customer-specic applications (e.g. RFID, LED, antenna)
8 CC613_D00381_07_M_XXEN/02.2023
