Technical data
6 Technical data
Tabular data
Insulation coordination acc. to IEC 60664-1/IEC 60664-3
Rated voltage 250 V
Pollution degree 2
Overvoltage category II within terminal H II
Overvoltage category III, terminal H and all other terminals III
Rated impulse voltage, terminal H and all other terminals 6 kV
Rated impulse voltage within terminal H 2.5 kV
Double insulation between terminal H and all other terminals OCV III
Basic insulation within terminal H OCV II
Operating altitude AMSL ≤ 2000 m
Supply voltage (terminal B (0V, +12V))
Nominal voltage DC 12 V
Operating range of the nominal voltage DC 11.4 V…12.6 V
Max. nominal current 750 mA
Max. nominal current without USB load 400 mA
Max. nominal current with USB load 750 mA
Residual direct current monitoring module* (RDC-M, terminal A)
Measuring range 100 mA
Response values:
Residual current I
Δn
DC 6 mA
Response tolerance I
Δn
-50…0 %
Measuring current transformers
Max. connection cable length ≤ 1.47 m
Restart sequence value:
DC 6 mA < 3 mA
* Patented 6 mA DC residual current trip
(Patent: EP 2 571 128/US 9,397,494/ZL 201210157968.6/CN 103001175, EP 2 813 856)
