CC613 charge controller
SMA plug connector* for 4G antenna (optionally with 4G modem, terminal E)
Frequency bands 800 MHz/850 MHz/900 MHz/1800 MHz/2100 MHz/2600 MHz
Impedance 50 Ω
Data rate GSM:
GPRS: UL 85.6 kBit/s; DL 107 kBit/s
EDGE: UL 236.8 kBit/s; DL 296 kBit/s
UMTS:
WCDMA: UL 384 kBit/s; DL 384 kBit/s
DC-HSDPA: DL 42 MBit/s
HSUPA: UL 5.76 MBit/s
LTE:
LTE FDD: UL 5 MBit/s; DL 10 MBit/s
LTE TDD: UL 3.1 MBit/s; DL 8.96 MBit/s
Specified antenna PSI-GSM/UMTS-QB-ANT
* SMA plug connector must be safeguarded against ESD discharges by the customer
Data interfaces
USB host 1 (terminal C1)* USB port type A; USB 2.0 max. 250 mA
USB host 2 (terminal C2)* USB port type A; USB 2.0 max. 250 mA
Ethernet (terminal D) 10/100 Mbit
CONFIG (configuration interface, terminal F) micro USB port type AB
SIM card (only with 4G modem, front panel) micro SIM
HMI (user interface, terminal K) internal
Modbus meter (terminal B) 9.6 kBit
External Modbus (terminal I) 9.6 kBit
Control Pilot (terminal B (CP)) acc. to IEC 61851
Proximity Pilot (terminal B (PP)) acc. to IEC 61851
* USB host 1 and USB host 2: in total 500 mA
CC613_D00381_07_M_XXEN/02.2023 29
