Technical data
Inputs (depending on the variant)
Optocoupler (terminal J (Opto 1 In+, Opto 1 In-))
Input voltage DC 11.4 V…25.2 V
Input current 2.3…6.4 mA
Weld check (terminal H (WB, WA))
Input voltage AC 180 V…277 V
Input current 0.6…1.3 mA
Input PE (terminal B (PE, PE))
Outputs (depending on the variant)
Contact data acc. to IEC 60947-5-1:
Relays (12 V) (terminal J (relay 13, relay 14))
Rated operational voltage U
e
DC 24 V
Rated operational current I
e
DC 1 A
Minimum contact rating DC 1 mA at ≥ 10 V
Switching contact for contactor (terminal H (relay 23, relay 24))
Rated operational voltage U
e
AC 230 V
Rated operational current I
e
AC 4 A
Minimum contact rating AC 50 mA at ≥ 10 V
Environment/EMC
EMC see CE declaration
Operating temperature -30…70 °C
Classication of climatic conditions acc. to IEC 60721:
Stationary use (IEC 60721-3-3) 3K23 (except condensation and formation of ice)
Transport (IEC 60721-3-2) 2K11
Long-term storage (IEC 60721-3-1) 1K21
Classication of mechanical conditions acc. to IEC
60721:
Stationary use (IEC 60721-3-3) 3M11
Transport (IEC 60721-3-2) 2M4
Long-term storage (IEC 60721-3-1) 1M12
30 CC613_D00381_07_M_XXEN/02.2023
