CC613 charge controller
Cable lengths/cable types
Cable Shielded, one end of shield connected
to PE
HMI (user interface, terminal K) (depending on the variant)
Connection cable RJ45, shielded
Max. connection cable length internal 2 m
Ethernet (terminal D)
Connection cable CAT 6
Max. connection cable length 100 m
Connection type (terminal blocks B and J) push-wire terminal
Connection specifications:
Rigid/flexible 0.2…1.5 mm² (AWG 24…16)
Flexible with ferrule without plastic sleeve 0.25...1.5 mm² (AWG 24…16)
Flexible with ferrule with plastic sleeve 0.14...0.75 mm² (AWG 26…18)
Stripping length 10 mm
Max. connection cable length 2 m
Cross-section ≥ 0.5 mm
2
Max. connection cable length (PE) 4 m
Cross-section (PE) ≥ 1 mm
2
Connection type (terminal blocks I) push-wire terminal
Connection specifications:
Rigid/flexible 0.2…1.5 mm² (AWG 24…16)
Flexible with ferrule without plastic sleeve 0.25...1.5 mm² (AWG 24…16)
Flexible with ferrule with plastic sleeve 0.14...0.75 mm² (AWG 26…18)
Stripping length 10 mm
Max. connection cable length 2 m
Cross-section ≥ 0.5 mm
2
Max. connection cable length (PE) 4 m
Cross-section (PE) ≥ 1 mm
2
CC613_D00381_07_M_XXEN/02.2023 31
