Connection
•
Connection is only possible when a micro SIM card is inserted in the SIM card slot located on the charge
controller front panel.
•
The SIM card can have a PIN number which can be congured via the Settings tab.
•
The APN settings for the SIM card can also be congured via the Settings tab.
CAUTION
Use of nano SIM cards with a corresponding SIM card adaptor
SIM card slot can be damaged
It is recommended to use only micro SIM cards.
The SIM card can be removed via push-push.
Use in the EU and other countries
Operation of device variants with an integrated 4G modem is only possible in member states of the European
Union, Lichtenstein, Iceland, Norway, Switzerland, Andorra, Monaco, San Marino, and the United Kingdom.
If 4G mobile networks are not supported, GSM mobile networks may also be used.
Antenna socket
The antenna socket enables connection to a 4G antenna (not included in the scope of delivery).
The following approved antenna type must be used: PSI-GSM/UMTS-QB-ANT.
ADVICE
Safeguard the antenna socket against ESD discharges!
If the antenna socket can be touched during operation, suitable measures must be implemented to
protect against ESD discharges.
22 CC613_D00381_07_M_XXEN/02.2023
