Appendix A
SPN/FMI Codes to Service Action Codes
SPN FMI DTC Diagnostic Trouble Codes (DTC) Description
Service
Action Code
(See 2.11)
1705 31
3, 4, 7-10, 12 Internal Error A
13 Internal Error B
14-16 Internal Error A
17, 20 Internal Error Q
21-35, 37-42 Internal Error A
43 Calibration data corrupt Q
44-46, 48,
49, 52-57
Internal Error A
58 Internal Error
Q
60 Image Processor Calibration error
61, 77, 81-86,
128-129
Internal Error A
140 Incompatible software version - Image Processor
I
141, 143-145 Internal Error
A
147 Camera temperature too high
1807
2 182
J1939: Brake controller signal invalid - VDC2 Steering Wheel
Angle
P
9 176
J1939: Brake controller signal invalid - VDC2 Steering Angle
Sensor
M
19 69 J1939: Brake controller signal error - VDC2 Steering Wheel N
1808
2 189 J1939: Brake controller signal invalid - VDC2 Yaw Rate P
9
63 J1939: Brake controller message missing - VDC2
M
190 J1939: Brake controller signal invalid - VDC2 Yaw Rate
19 70 J1939: Brake controller signal error - VDC2 Yaw Rate N
1809
2 191 J1939: Vehicle controller signal invalid - VDC2 Lateral Accel P
9 192 J1939: Brake controller signal missing - VDC2 Lateral Accel M
19 71 J1939: Brake controller signal error - Lateral Accell
N
2347 19 156
J1939: Vehicle controller signal error - LCMD High Beam
Headlamp
2348 19 158 J1939: Vehicle controller signal error - LD High Beam Headlamp
2349 19 155
J1939: Vehicle controller signal error - LCMD Low Beam
Headlamp
2350 19 157 J1939: Vehicle controller signal error - LD Low Beam Headlamp
2367 19 76 J1939: Vehicle controller signal error - LCMD Left Turn
2368
2 164 J1939: Vehicle controller signal error - VP37 Left Turn Signal
19 68 J1939: Vehicle controller signal error - LD Left Turn
2369
9 79 J1939: Vehicle controller message missing - LCMD M
19 75 J1939: Vehicle controller signal error - LCMD Right Turn N
Note: The system will not report newly active J1939 DTCs until the engine has been
running for 15 seconds. Do not attempt to diagnose J1939 DTCs without the engine running.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
