BENDIX AUTOVUE FLC-20 User Manual

25
Appendix A
SPN/FMI Codes to Service Action Codes
SPN FMI DTC Diagnostic Trouble Codes (DTC) Description
Service
Action Code
(See 2.11)
2370
2 165 J1939: Vehicle controller signal error - VP37 Right Turn Signal N
9 62 J1939: Vehicle controller message missing - LD M
19 67 J1939: Vehicle controller signal error - LD Right Turn N
2550 9 139 J1939: Brake controller message missing - Prop FLC Status
M
2863
14 199 J1939: Vehicle controller message missing - OWW
19 187 J1939: Vehicle controller signal error - OWW Wiper
N
2874 19 160
J1939: Vehicle controller signal error - OEL High-Low Beam
Switch
2875
9 194 J1939: Brake controller signal invalid - OEL Hazard Switch M
19 80 J1939: Vehicle controller signal error - OEL Hazard Switch N
2876
2 180 J1939: Vehicle controller signal invalid - OEL Turn Signal Switch P
9
65 J1939: Vehicle controller message missing - OEL
M
195 J1939: Vehicle controller signal invalid - OEL Turn Signal
19 66 J1939: Vehicle controller signal error - OEL Turn Signal
N
3564
4 153
J1939: Vehicle controller signal error - FLIC LDW Enable
Command
9 173
J1939: Vehicle controller signal invalid - FLIC LDW Enable
Command
M
14 134 J1939: Vehicle controller message missing - FLIC
19 153
J1939: Vehicle controller signal error - FLIC LDW Enable
Command
N
4011 9 183
J1939: Vehicle controller signal invalid - OEL High Beam
Headlamp
M
516096 19 148 J1939: Vehicle controller signal error - LDW Enable Switch N
516097
2 193 J1939: Vehicle controller signal invalid - FLIC Prop Speaker P
9 174 J1939: Speaker controller signal invalid - FLIC Prop Speaker M
18 193 J1939: Vehicle controller signal invalid - FLIC Prop Speaker P
19 154
J1939: LDW Speaker controller signal error - FLIC Prop
Speaker
N
516098
2 188 J1939: Vehicle controller signal error - OEL High Beam
19 161 J1939: Vehicle controller signal error - OEL High Beam Status
516099
9 186 J1939: Vehicle controller signal invalid - Windshield Wiper M
19 162 J1939: Vehicle controller signal error - OEL Wiper
N
516100 19 164 J1939: Vehicle controller signal error - VP37 Left Turn Signal
516101 19 165 J1939: Vehicle controller signal error - VP37 Right Turn Signal
516102 19 166 J1939: Vehicle controller signal error - VP37 High Headlamp
516103 19 167 J1939: Vehicle controller signal error - VP37 Hazard Lamp
516104 19 168 J1939: Vehicle controller signal error - VP37 Wiper Status
Note: The system will not report newly active J1939 DTCs until the engine has been
running for 15 seconds. Do not attempt to diagnose J1939 DTCs without the engine running.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
Appendix A (Pages 22–25)
