BENDIX VORAD VS-400

33
Electrical Requirements
J1939
Note: The illustration above shows J1939/11, however J1939/15 (2-wire) can be used.
Pin # Description
J1-6 J1939-
J1-7 J1939+
Terminating
resistor
J-1939/15 data link
(OEM supplied)
Terminating
resistor
1
2
4
3
8
5
7
6
