45
Appendix
Connector Pin Descriptions
Forward Looking Radar
10-pin TRW Connector
Driver Interface Unit
8-Pin Molex Connector
PIN # SIGNAL NAME TYPE INTERFACE LEVEL
1 NO_CONNECTION – –
2 NO_CONNECTION – –
3 J1939_SHIELD TRUCK J1939 LINK
4 CAN_HI – TRUCK J1939 LINK
5 CAN_LO – TRUCK J1939 LINK
6 NO_CONNECTION – –
7 NO_CONNECTION – –
8 NO_CONNECTION – –
9 GROUND POWER CHASSIS GROUND
10 IGNITION POWER +12V SWITCHED
PIN # SIGNAL NAME TYPE INTERFACE LEVEL
1 RIGHT_SPEAKER O SPEAKER DRIVER 4 OHM / 1 WATT
2 LEFT_SPEAKER O SPEAKER DRIVER 4 OHM / 1 WATT
3 BLACKOUT_INPUT / SPARE I TRI-STATE INPUT
4 BATTERY POWER +9-32VDC SWITCHED
5 GROUND POWER CHASSIS GROUND
6 CAN_LO TRUCK J1939 LINK
7 CAN_HI TRUCK J1939 LINK
8 SPARE_ANALOG I TRI-STATE INPUT
