Appendix

Side Sensor Display Unit

4-pin Deutsch Connector

Side Sensor

6-pin Deutsch Connector

PIN # SIGNAL NAME TYPE INTERFACE LEVEL

1 POWER I +12V FROM SENSOR

2 GROUND POWER CHASSIS GROUND

3 COMMUNICATION I

4 TURN_SIGNAL I +12V

PIN # SIGNAL NAME TYPE INTERFACE LEVEL

1 IGNITION POWER +12V SWITCHED

2 GROUND POWER CHASSIS GROUND

3 COMMUNICATION O

4 POWER O +12V

5 SODDU-GROUND POWER GROUND

6 NO CONNECTION – –
