BENDIX VORAD VS-400

General Information
40
Appendix 3 continued
Fine-Tuning the Horizontal Alignment
Ifthealignmentfunctioninthediagnosticsoftwarecontinuouslyshowsanazimuthvaluegreaterthan0.5°orlessthan-0.5°,thentheFLR
needs to be physically adjusted in the horizontal direction beyond that already completed.
Center FLR Azimuth Position (FLR aligned correctly)
Ifthealignmentfunctionconsistentlyshowsanazimuthvalueof0°+/-0.5°whentrackingavehicleinthesamelane,thentheFLRis
properly centered. In this case, the FLR does not need to be further aligned and the procedure is complete.
