HD-7P / HD-7W Four-Post Lifts 9 P/N 5900041 — Rev. M — July 2019
Model
HD-7P HD-7W
Lifting capacity
7,000 lbs / 3,175 kg
Maximum capacity front axle
3,500 lbs / 1,750 kg
Maximum capacity rear axle
3,500 lbs / 1,750 kg
a Minimum Runway Height
4.5" / 114 mm
b Maximum Rise
82"/ 2,083 mm
c Maximum Lifting Height
87" / 2,208 mm
d Overall Width
100.25" / 2,546 mm 110.25" / 2,800 mm
e Outside Length
174" / 4,418 mm
f Overall Length
200" / 5,078 mm
g Height of Posts
100" / 2,537 mm
h Distance Between Posts
90.25" / 2,292 mm 100.25" / 2,546 mm
i Drive-Through Clearance
76.5" / 1,943 mm 86.5" / 2,197 mm
j Runway Width
19" / 482 mm
k Runway length
164.5" / 4,178 mm
l Width Between Runways
38" / 963 mm 38" / 963 mm or 44.25" / 1,121 mm
m Runway Centerline
56.5" / 1,437 mm 56.5" / 1,437 mm or 63.5" / 1,610 mm
n Outside Edge of Runways
75.5" / 1,919 mm 75.5" / 1,919 mm or 82.5" / 2,092 mm
Min. Wheelbase @ rated capacity
1
115" / 2,921 mm
Min. Wheelbase @ 75% capacity
1
100" / 2,540 mm
Min. Wheelbase @ 50% capacity
1
85" / 2,159 mm
Min. Wheelbase @ 25% capacity
1
70" / 1,778 mm
Locking Positions
17, spaced every 4" / 102 mm
Lifting time
~35 seconds
Motor
208-230 VAC, 60 Hz, 1 Ph
Max normal operating pressure 208-230 VAC: 2,600 PSI
Power Unit PRV setting 208-230 VAC: 2,900 PSI
Sound (when raising/lowering) <70 dBA
Air supply 3 to 25 cfm at 50 to 150 psi
1
The Lift supports less weight than its rated capacity when the Vehicle’s wheelbase is shorter; this is
because the wheels are closer to the middle of the Runways, where there is less strength.
Specifications subject to change without notice.
