DIMENSIONS ARE IN MM
☺
1
3
2
5
4
ISOMETRIC VIEW
FOR REFERENCE ONLY
DO NOT SCALE
ITEM
NO
PART
NUMBER
DESCRIPTION
QTY
REV
1 5601303
HD-7500/9 CYLINDER FLANGE ARM WELDMENT
1
B
2 5715031
HD-7500/9/973 CYLINDER CABLE BLOCK ARM SLIDE
2
B
3 5530244
FHPS M6 x 1.0 x 20mm
4
-
4 5535357
NUT M6 x 1.0 NL
4
-
5 5545005
WASHER, M6 x 12mm FLAT
4
-
NEXT ASSEMBLY
5215190
5215192
5215512
5215525
5216058
WHERE USED
HD-9 SERIES
HD-75BXT
HD-7500BL SERIES
PL-12000DP
REVISION
REV
DESCRIPTION
DATE
EDITED BY
ECO#
A
PRODUCTION RELEASE, DERIVED FROM 5215129
01/29/2019
TM
01039
B
UPDATED TITLE TO REFLECT WHERE USED,
UPDATED BOM REVISIONS AND NEXT ASSEMBLIES
12/20/2019
TM
01120
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
B
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
BENDPAK INC.
IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED
.
TM
5215820
HD-7500/9 CYLINDER
FLANGE ARM ASSEMBLY
01/28/2019
DO NOT SCALE DRAWING
1:2
SCALE:
THIRD ANGLE PROJECTION
OR
04/20/2020
REFER TO MODEL FOR ADDITIONAL INFORMATION
1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING
2.
ASSEMBLE ITEMS AS SHOWN
3.
To Next Page
