P-9000LT/F Low-Rise Pit Lift 9 P/N 5900022 — Rev. B — Nov. 2019
Model P-9000LT P-9000LTF
Style Surface mount Flush mount
Lifting capacity 9,000 lbs. / 4,082 kg
A Lifting height
23.75" / 603 mm 20.25" / 515 mm
Lifting height + Block
26" / 658 mm 22.5" / 570 mm
B Overall Platform length
58.5" / 1,484 mm
C Overall length
124.5" / 3,165 mm (with ramps) 74.5" / 1,890 mm (no ramps)
D Lowered height
3.15" / 80 mm 0" / 0 mm
E Platform width
24" / 610 mm
F Width between Platforms
36 to 42" / 914 to 1,066 mm
G Max distance to Console*
Up to 30" / 762 mm
Maximum hydraulic pressure 2,800 PSI
Lifting time ~35 seconds
Motor** 208 – 240 VAC, 50/60 Hz, 1 Ph; 30 amp or greater breaker
Sound <70 dB
* With supplied Hydraulic Hoses and Covers.
** 110 VAC units available on request. Lift loses ALI certification if used with a 110 VAC Power Unit.
Specifications subject to change without notice.
