DANGER!
DO NOT run power unit with no oil. Damage to pump can occur.
The power unit must be kept dry. Damage to power unit caused by water or other liquids such as
detergents, acid etc., is not covered under warranty.
Operate lift only between temperatures of 41 °- 104° F.
Improper electrical hook-up can damage motor and will not be covered under warranty.
Motor can not run on 50HZ without a physical change in motor.
Use a separate breaker for each power unit.
Protect each circuit with time delay fuse or circuit breaker.
For 208-230 volt, single phase, use a 25 amp fuse.
For 208-230 volt, three phase, use a 20 amp fuse.
For 380-440 volt, three phase, use a 15 amp fuse.
STEP SIX
( Power Unit Hook Up )
1. Have a certifi ed electrician run 208 - 230 volt single
phase 60 HZ power supply to motor. ( If you ordered op-
tional three phase power or 50HZ, refer to the data plate
found on the motor for proper power supply. ) Be sure to
size wire for a 25 amp circuit.
RISK OF EXPLOSION!
This equipment has internal arcing or parts that may
spark and should not be exposed to fl ammable vapors.
Motor should not be located in a recessed area or below
fl oor level. NEVER expose motor to rain or other damp
environments. DAMAGE TO MOTOR CAUSED BY
WATER IS NOT COVERED UNDER WARRANTY.
WIRING DIAGRAM
IMPORTANT NOTE:
DO NOT USE 110 VOLT POWER SUPPLY
for this power unit. Damage to motor will occur
which is not covered under warranty. You must
use a separate circuit breaker for each lift.
DANGER !
ALL WIRING MUST BE PERFORMED
BY A LICENSED ELECTRICIAN.
DANGER!
DO NOT PERFORM ANY MAINTENANCE OR
INSTALLATION OF ANY COMPONENTS WITH OUT
FIRST ENSURING THAT ELECTRICAL POWER HAS
BEEN DISCONNECTED AT THE SOURCE OR PANEL
AND CANNOT BE RE-ENERGIZED UNTIL ALL
MAINTENANCE AND/OR INSTALLATION
PROCEDURES ARE COMPLETED.
