BendPak XPR-10S User Manual

36
If the lift was provided with Lift Arm Foot Guards, install the shorter Foot Guard on the shorter
Arm Assembly and the longer Foot Guard on the longer Arm Assembly.
To install, rmly squeeze the ends of the Foot Guard inwards and insert the ends
underneath the bent ends of the arm support. Release to allow the Foot Guard to spring into
place. Check to be sure that Foot Guard is rmly in place.
Repeat this step for each Arm Assembly Foot Guard.
Arm Support
