BendPak XPR-10S - Page 70

70
3678
2679-3009
113-1865.6mm [4.4-73.4"]
214-1966.6mm [8.4-77.4"]
WITH 63mm [2.5"]
2364-
2694
DRIVE THRU
3353-
3683
3219-3549
733-1194mm
SHEET 2 OF 2
REV
DWG. NO.
A
SIZE
TITLE:
A
1645 LEMONWOOD DR. SANTA PAULA, CA 93060
5260566
XPR-10S-LP
PRODUCTION LIFT VER E
1:45
SCALE:
