15
STEP 9
( Installing The Hydraulic Lines. )
1. Connect the two Cyliinder Hydraulic Hoses in line to
the Tee Fitting. Connect the 90* Fitting to the Tee Fitting.
Connect the Power Unit Hose to the 90* Fitting.
(See Fig 9.1)
2. Connect the Cylinder Hoses to the Straight Fittings
on the Cylinders. DO NOT use Teflon Tape on the JIC
Fittings. (See Fig 9.2)
3. Route the Power Unit Hose between the Cylinder
Shaft and the Equalizer Pulley Bracket. Route the Hose
through the retaining rings. Failure to do so may cause
damage or injury. (See Fig 9.3)
4. Remove the plastic plug from the Power Unit Power
Port. Install the 90* Power Unit Fitting with O-Ring using
Teflon tape. (Connect the Power Unit Hose Assembly
to the 90* Hydraulic Fitting on the Power Unit. DO NOT
use Teflon tape on the JIC Hose fittings. (See Fig 9.4)
WARNING !
When routing Hydraulic Hoses through the Columns,
route Hoses through the retaining rings welded on each
Column. Make sure that the Hose is clear of any
moving parts. It may be necessary to tie Hose clear by
using nylon tie straps or wire. Failure to keep Hydraulic
Hoses clear may result in Hydraulic Hose failure which
may result in damage or personal harm.
Fig 9.1
Fig 9.3
Fig 9.2
Fig 9.4
NOTE:
Location of Power Port in Hydraulic Unit may vary.
Confirm Location of Power Port on Power Unit
Documentation.
