STEP 10
( Routing The EQUALIZER CABLES )
1. With the Carriages raised equal height off the floor,
route the Equalizer Cables. (See Fig. 10.1)
16
DANGER !
Make sure that the Safety Locks on each column
are fully engaged before attempting to route
Equalizer Cables and/or hoses. Carriages must be
equal height from the floor before proceeding.
WARNING!
WHEN THE CABLE ADJUSTING NUTS BOTTOM
OUT ON THE THREADED END OF THE CABLE
CONNECTOR AND THERE IS STILL SLACK IN
THE CABLES, THE CABLES HAVE STRETCHED
BEYOND THE SAFE USEFUL LENGTH AND NEED
TO BE REPLACED WITH FACTORY APPROVED
CABLE ASSEMBLIES. DO NOT PLACE WASHERS,
SPACERS OR OTHER DEVICES TO “SHORTEN”
THE EFFECTIVE CABLE LENGTH AS DAMAGE TO
THE LIFT OR INJURY TO PERSONS MAY OCCUR.
Fig. 10.1
WARNING !
The Equalizer Cable Pulleys will need to be
removed to ease the routing of the Equalizer
Cables. Be sure to reinstall all pins, covers and
clips or serious damage or injury may occur.
