Rebound damping adjustment
The rear suspension rebound damping can be adjusted by the
adjusting knob in the lower end of rear suspension. To adjust the
rebound damping, please follow the procedure:
1. Turn the adjust knob as illustrated until feeling tight and no click
sound heard, this is the zeroing point with maximum rebound damping
eFect (rebound extremely slow).
2. Turn the adjust knob in opposite direction, and count for clicking sound. The total adjustable range is 36 clicks
from the zero point, in normal riding, the setting should be 5~10 clicks according to the road condition and rider's
preference.
Generally speaking, when the spring preload is increased, the rebound damping should also be increased
accordingly. If you are not sure how to adjust the rear suspension correctly, please refer to the authorized dealers
for technical advice.
Alarm :
Rotate this adjusting knob with hand only, and never use too much force, or the rear suspension will be
damaged. This will be deemed as abnormal usage, will not be covered by warranty.
