BenQ DC 5530 User’s Manual
Preparing your DC C50 for using
5
English
2.3. How to charge the Battery:
2.4. Loadig an SD Memory Card:
All images and video clips taken by the camera can be stored in an SD (Secure Digital)
Memory Card.!Even if the cameraís power is OFF, the images saved in the SD Memory Card
are not erased. An SD Memory Card can be repeated read and written.
1.!Make sure the camera power is off.
2.!Slide the battery/SD Memory Card cover into the direction of the [OPEN] arrow.
3.!Insert the battery, noting correct polarity (+ and -).
4.!Slide the battery lock lever to adjust the battery.
5.!Close the battery/SD Memory Card cover firmly.
6.!Connect one end of the AC power adapter to the DC IN 5V terminal.
7.!Connect the other end of the AC power adapter to a power outlet.
Charging start: Green indicator
Charging end: Indicator off
Stand by: Orange indicator
Replace a new battery: Red indicator
Note
•
Make sure to use only the AC power adapter specified for the camera. Damage caused
by the use of an incorrect adapter is not covered under the warranty.
• When the charging is not started even if proceeding the operation above. Press power
button on at any mode after LCD indication appears, then turn the power off.
• Do not place the camera in hot temperature. Use it at room temperature.
1.!Make sure the camera is off.
2.!Slide the battery/SD Memory Card cover in the
direction of the [OPEN] arrow.
3.!Insert an SD Memory Card :
• The front side of the memory card(printed arrow)
should face towards the front side of the camera.
• If the card cannot be inserted, check the orientation.
4.!Close the battery/SD Memory Card cover.
• To remove the SD Memory Card, make sure!the
camera is off. Open the battery/SD Memory Card card cover.
Press lightly on the edge of the memory card and it will eject.
