BenQ DC 5530 User’s Manual
English
Using the DC E53+
15
3.3.1 Playback Mode LCD Monitor Information (Image)
1. Playback mode
2. Frame number
3. SD memory card indicator (if present)
4. Battery power indicator
5. Image size (resolution)
6. Camera mode
3.3.2 Viewing Images
3.3.2.1 Rotating Images
Pressing the S/T buttons during image playback will rotate the image 90 degrees. The S
button rotates the image clockwise, whereas the T button rotates the image
counterclockwise.
3.3.2.2 Magnifying Images
While reviewing your images, you may enlarge a selected portion of an image. This
magnification allows you to view the details of the image. The DC E53+ provides 8X
magnification during playback.
1. Adjust the zoom ratio by using the zoom button.
• To enlarge the selected image, press the T button.
• To return to normal magnification, press the W
button.
• The magnification factor is displayed on the LCD
monitor.
2. To view different portion of the images, press the
S/T/W/X buttons to adjust the display area.
You will see a white frame with a pink box inside. The white frame indicates the entire
image, while the pink box shows the location of the currently enlarged area.
3. To return to regular display, press the W button until the normal image (1X
magnification) appears on the screen.
Notes
•
If there is no image stored in the internal memory or memory card, a
[NO PICTURE] message will appear on the monitor.
• Pressing the button while playing back images changes the LCD
display in the sequence of: Standard display
→ Detailed display → No
information.
1 2 3
6
4
5
90 Counterclockwise
o
0 (Original)
o
90 Clockwise
o
3x
