BenQ ES500 - Projector Exterior View

Introduction10
Projector exterior view
1. External control panel
(See "Projector" on page 11 for
details.)
2. Lamp cover
3. Focus ring
4. Front IR remote sensor
5. Elevator foot
6. Projection lens
7. Kensington anti-theft lock slot
8. Vent holes
9. Zoom ring
10. RGB (PC)/Component video
(YPbPr/ YCbCr) signal input jack
11. RS-232 control port
12. Video input jack
13. Mini-B USB input jack
14. AC power cord inlet
15. Rear adjuster foot
16. Ceiling mount holes
Front/upper side
7
1
2
3
4
8
6
5
9
9
Rear/lower side
11
10
12
13
15
14
16
5
7
8
