Specifications
66
Dimensions
285.0 mm (W) x 117.2 mm (H) x 205.8 mm (D)
Ceiling mount installation
285.0
205.8
117.2
Unit: mm
67.6
Ceiling Mount screw: M4
(Max L = 25 mm; Min L = 20 mm)
Unit: mm
